P4 Indoor Window Screen 1104×2128mm



2 Yıl ürün garantisi
10 Yıl yedek parça garantisi


Mağaza Bilboard Led Ekran

Engage people with advertising content at eye level as they walk through your shop. The fascinating appearance of LED displays makes advertising attractive. Plug-on and play function is very suitable for chain store, hotel, shopping mall etc. See our cases to find one that best suits your needs and budget.

HD Shop Window LED Screen

Indoor Window LED Screen features different display modes which you may change as per your needs. Beautiful design and crystal-clear displays catch eyes easily. Shop window LED screen changes static display to dynamic for better advertising effects.



Easy to Setup and Information Transmission

With different controlling and display options like 3G and Wi-Fi control, the display is easy to operate from anywhere. Show real time information transmitted through 3G or Wi-Fi. Can be used at crowded places like shopping mall, supermarket and others to show your ad.



Reasonable Design - Simple but Practical

Indoor Window LED Screen features a beautiful iPhone shape measuring 1104mm, 2128mm and 150mm in length, height and width respectively. It's lighter and 50-80% thinner than traditional advertising players which make it easy to transport and install.



Yüksek Parlaklık,Daha iyi Kalite

Dış mekanlarda ekanlarımız yüksek parlaklıklı çıktıları destekler.Yüksek parlaklığı ve yüksek çözünürlüğü ile vitrin LED ekranı mükemmel görüntü ortaya çıkarır.Mağaza,Dükkan,Show room,promosyon ve birçok dış mekanlarda şahane bir şekilde durur.



Unique Design - Easy to Install & Transport

The cabinet of Indoor Window LED Screen features unique rugged design which makes it easy to carry and install. The lightweight cabinet is easy to carry and saves transportation cost. It's damage free and lasts for a lifetime.



Beautiful Display - Attracts more Customers

It features different display modes which you may change as per your needs. Beautiful design and crystal-clear displays catch eyes easily. Shop window LED screen changes static display to dynamic for better advertising effects.



Seamless Display and Visual Effects

The advanced assembled structure produces seamless display and visual effects, offering you the perfect visual performance you desire from your LED Screen for Showcase Advertising. The picture quality remains high due to best quality display material.


LED Lamp
Type SMD2121 black body
Brand Kinglight
Arrangement 1R1G1B
Chip parameters Red (620-625nm) IV:(250-300mcd )
Chip parameters Green (520-525nm) IV:(450-550mcd)
Chip parameters Blue (470-475nm) IV:(100-120mcd)
LED Module
Pixel Pitch 4mm
Module Size 256×128mm
Module Resolution 64×32=2048(Dots)
Module Weight 0.23kg
LED Cabinet
The entire screen size(W*H*D) 1104×2128×150mm
Working Temperature -15℃~50℃
Display Dimension(W*H) 1024×2048mm
Humidity 15%~85%
Resolution W*H(dots/set) 256×512=131072dots
Frame Frequency no less than 60 frame/sec
Cabinets Material Steel
Input Voltage AC110-220V±10%,50/60Hz
Cabinet Weight 160kg
Output Voltage DC-5V,40A/60A/80A
Brightness ≥1300cd/㎡
Color Grayscale 16bit
Gray Scale per Color 65536 level
Viewing Angle 140(Horizontal),140(Vertical)
Color Processing R(1024)×G(1024)×B(1024)
Nearest Viewing Distance 5m
Brightness Adjustment 256 color levels,can be adjusted manually and automatically optional
Total Power Consumption (Max) 1300W/H
MTBF( mean time between failures) 5000 hours
Total Power Consumption (Average) 380W/H
Life-span 100,000 hours
Refresh Rate ≥1000Hz
Protection Level(front/back) IP54/IP43
Drive Mode/Driver Position Constant driving 1/16 Scan,Combined diver board
Malfunction Dot Rate less than 0.0001
Display Function Text,Graphics,Video
Control System
Control Mode Synchronization/Asynchronization
Input Signal AVI/MPG/MPEG/TXT.etc
Control System Sending Card, Receiving Card,Receiving HUB
PC Operating System Microsoft Windows 10 ,Windows 7 and XP
Software Led show
Communication Type WIFI, Net cable,3G(Sold separately)
Language Chinese,English
Certificate CE,ROHS,FCC,ISO9001,TUV
Control Card Input RJ45,HDMI,USB
