LGAOMP01.5CL
OUTDOOR FINE PITCH LED SCREENS FOR
DIGITAL OUT-OF-HOME MESSAGING &
PROFFESSIONAL INSTALLATIONS
DIGITAL OUT-OF-HOME MESSAGING &
PROFFESSIONAL INSTALLATIONS
Ürün görseli buraya
▣
New generation full-flip chip microLED technology
☀
Adjustable brightness optionally up to 6.500 nits
◍
Production level calibration for best color uniformity
🛡
Aluminum fanless design for high performance under extreme conditions
✒
Lightweight for easy adaptation and low cost framework design
⚡
Lower power consumption with common-cathode technology
Yaşam tarzı / araba görseli buraya
LEDGARANTİ OUTDOOR
FINE PITCH SOLUTIONS
FINE PITCH SOLUTIONS
1- Panel dimensions can change upon customer request
2- That value is the remain capacity of PSU's at 100% brightness and white color content
3- Different types of video input available as option
2- That value is the remain capacity of PSU's at 100% brightness and white color content
3- Different types of video input available as option
IDEAL FOR
🖥
DOOH
Advertising
🛍
Shopping
Malls
🏟
Stadiums
🏢
Corporate
Buildings
🚆
Transport
Hubs
🖳
Control
Rooms
ADVANCED FEATURES
Front Access
Lightweight
Slim
Temp Monitoring
Smoke Monitoring
Voltage Monitoring
Remote Control
Easy To Install
Wide Angle
High Refresh Rate
Transparent
Noiseless
Calibration
Pixel Detection
Fanless
TECHNICAL SPECIFICATIONS
GENERAL
| Chipset | : | |
| Operating environment | : | outdoor |
| Pixel pitch | : | 1.53mm |
| Service type | : | front and rear access |
| Calibrated brightness (nits) | : | 3.800 nits |
| Lamp type | : | Flip-Chip Micro |
| Lifespan (hours at %50 brightness) | : | >80.000 hours |
| White color calibration (adj.) | : | 3.500K~8.500K |
| Gray scale | : | >24 bits |
| Brightness control | : | 256 level |
MODULE SPECIFICATIONS
| Module dimensions (mm) | : | 160x360 |
| Refresh frequency | : | 3.840Hz |
| Module resolution | : | 104x232px |
| LED drive method | : | dynamic |
| Module material | : | aluminum |
| Module type | : | sealed |
| PCB type | : | multilayer |
| Surface coating | : | UV resistant & high contrast |
PANEL SPECIFICATIONS
| Panel material | : | aluminum |
| Panel paint | : | ES powder coated |
| Panel dimensions (mm) | : | 640x360 |
| Panel depth | : | 70mm |
| IP level | : | IP65 rear |
| Panel weight | : | 8.5 kg |
| Panel resolution | : | 416x232px |
| Pixel density (pcs/sqm) | : | 418.888 |
| Viewing angle (horizontal x vertical) | : | 175° x 160° |
| Minimum viewing distance | : | >1.5m |
| Operating temperature range | : | -20°C ~ +40°C |
| Storage temperature range | : | -30°C ~ +60°C |
| Operating humidity | : | 10% ~ 80% non-condensing |
| Power input voltage | : | 100 ~ 240 VAC |
| Power input frequency | : | 50~60Hz |
| Average power per sqm | : | <200W |
| Max power per sqm | : | <600W |
| Active PFC | : | YES |
| Load tolerance | : | 25% min. |
| Panel installation type | : | Fixed installation |
| Cooling | : | Passive cooling without fan |
OTHER
| Max input resolution | : | FHD, UHD, 4K, 8K |
| Standard video sources | : | All digital formats |
| Brightness adjustment | : | Automatic & manual |
| Death pixel monitoring | : | Optional |
| Module monitoring | : | YES |
| Temperature monitoring | : | YES |
| Smoke monitoring | : | Optional |
| Voltage monitoring | : | YES |
| Power redundancy | : | N/A |
| Signal path backup | : | YES |
| Signal transmission | : | CAT or Fiber Optic |
| Standby scheduling | : | YES |
| Power on/off scheduling | : | Optional |
| Power saving mode | : | YES |
| Certification | : | CE-EMC, CE-LVD, RoHS, FCC |
OPTIONS
| Contrast ratio | : | 10.000:1 |
| Higher Brightness - CLX | : | 6.500 nits |
| Corner installation | : | N/A |
