Dış Mekan Led Ekran sistem ve çeşitleri Led Garanti'de. Reklamcılık içeriğine sahip kişileri mağazanızdan geçerken göz hizasında tutun. Dış mekan led ekran büyüleyici görünümü, reklamcılığı cazip hale getiriyor. Tak ve çalıştır özelliği, zincir mağaza, otel, alışveriş merkezi vb. Için çok uygundur. İhtiyaçlarınıza ve bütçenize en uygun olanını bulmak için durumlarımıza bakın led ekran iç mekan ve dış mekan led ekran tasarımlarıyla led ekran fabrikası led garanti en iyisini size sunar
| LED Lamp | |
| Type | SMD2121 black body |
| Brand | NationStar INC2153S 7680HZ |
| Arrangement | 1R1G1B |
| Chip parameters | Red (605-630nm) IV:(65-130mcd) |
| Chip parameters | Green (520-528nm) IV:(225-255mcd) |
| Chip parameters | Blue (450-473nm) IV:(43-83mcd) |
| LED Module | |
| Pixel Pitch | 3.91mm |
| Module Size | 250×250mm |
| Module Resolution | 64×64=4096(Dots) |
| Module Weight | 0.48kg |
| LED Cabinet | |
| Pixel Density | 65536 Dots/sqm |
| Frame Frequency | no less than 60 frame/sec |
| Cabinet Resolution | 256×256=65536(Dots) |
| Input Voltage | AC110-220V±10%, 50/60Hz |
| Cabinet Dimension(W*H*D) | 640×640×95mm |
| Output Voltage | DC-5V, 40A/60A/80A |
| Module Quanty /Cabinet | 2×4=8(Pcs) |
| Color Grayscale | 16bit |
| Gray Scale per Color | 65536 level |
| Cabinets Material | Aluminum alloy Cabinet |
| Color Processing | R(1024)×G(1024)×B(1024) |
| Cabinet Weight | 15kg/PCS |
| Brightness Adjustment | 256 color levels, can be adjusted manually and automatically optional |
| Brightness | >5500cd/sqm |
| MTBF( mean time between failures) | 5000 hours |
| Viewing Angle | 140(Horizontal), 140(Vertical) |
| Life-span | 100, 000 hours |
| Nearest Viewing Distance | 5m |
| Protection Level(front/back) | IP31/IP54 |
| Power Consumption (Max) | 1300 w/sqm |
| Malfunction Dot Rate | less than 0.0001 |
| Power Consumption (Average) | 400 w/sqm |
| Operating Temp/Humidity | 0oC-45oC,15%~85%RH |
| Display Function | Text, Graphics, Video |
| Storage Temp/Humidity | -15oC-50oC,15%~85%RH |
| Refresh Rate | >7680HZ ICN2153S |
| Drive Mode/Driver Position | Constant driving 1/32 Scan, Combined diver board |
| Control System | |
| Control Mode | Synchronization/Asynchronization |
| Input Signal | AVI/MPG/MPEG/TXT.etc |
| Control System | Sending Card, Receiving Card, Receiving HUB |
| PC Operating System | Microsoft Windows 10 , Windows 7 and XP |
| Software | LED Studio(HSTV-linsn) |
| Communication Type | Net cable; 3G, WIFI(Sold separately) |
| Language | Chinese, Traditional Chinese, English, French, Japanese, Russian, Thai, Spanish, Polish, Italian, Portuguese, Turkish, Dutch, Greek, Bulgarian, Romanian, Arabic, Korean, German |
| Certificate | CE, ROHS, FCC, ISO9001, TUV |
| Control Card Input | DVI, USB, RJ45, HDMI(Sold separately) |
